Rode Caster DUO DJ Console (RCDUO)

Connectivity and Interfaces:
• 2 × Neutrik® XLR/TRS combo inputs
• 2 × 6.35 mm TRS balanced line outputs
• 2 × 6.35 mm headphone outputs + 1 × 3.5 mm TRRS input
• 2 × USB-C ports (connect two computers or smart devices)
• Bluetooth® for phone call integration
• Ethernet and built-in Wi-Fi
• Kensington lock slot

Audio Performance:
• Sample rate – 48 kHz
• Bit depth – 24 bit
• Revolution Preamps™ with 0–76 dB gain range
• Microphone input impedance – 4 kΩ
• Instrument input impedance – 1 MΩ
• Frequency response – 20 Hz – 20 kHz
• APHEX® processing_ Big Bottom™, Compellor™, Aural Exciter™
• Headphone output power – 250 mW

Control and Features:
• 4 physical + 3 virtual faders (7 channels total)
• 6 programmable SMART pads with bank switching
• Built-in wireless receiver for RØDE Wireless GO II / Wireless ME
• Bluetooth® call mix-minus support
• Direct recording to MicroSD card or USB-C drive

Power Supply:
• Power source – USB-C PD
• Voltage – 9 V
• Current – 3 A

Package Contents:
• RØDECaster Duo console
• SC27 USB-C to USB-C cable
• Power adapter
• Quick start guide
