Cooler Master MPE-C501-AFCAG-EU MWE Gold V2 Power supply 1250W Black (MPE-C501-AFCAG-EU)

• Model: MPE-C501-AFCAG

• ATX Version: ATX 12V V2.52

• Series: MWE Gold Series

• Category: Above 750W

• Wattage: 1050W

• Form Factor: ATX

• Modular: Fully Modular

• 80 Plus Efficiency: Gold

• Warranty: 10 years

Electrical Specs

• Input Voltage: 100–240 V

• Input Current: 15–7 A

• Input Frequency: 47–63 Hz

• Efficiency: ≥90% @ typical load

• PFC: Active PFC

• Operating Temperature: 0–50°C

• Power Good Signal: 100–150 ms

• Hold Up Time: >20 ms at 100% load

• MTBF: >100,000 hours

Design & Cooling

• Dimensions (L x W x H): 180 x 150 x 86 mm

• Fan Size: 140 mm

• Fan Type: FDB

• Fan Speed: 2200 RPM

• Noise @20%: 0 dBA

• Noise @50%: 15.8 dBA

• Noise @100%: 30.1 dBA

Connectors

• ATX 24-pin: 1

• EPS 4+4-pin: 1

• EPS 8-pin: 1

• SATA: 12

• Peripheral 4-pin (Molex): 4

• PCI-e 6+2-pin: 8

Protection & Certification

• Protections: UVP / OVP / OPP / OTP / SCP / OCP

• Certifications: TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA

• Compliance: ErP 2014 Lot 3
